Temporary Structures

Non-Insulated versatile modular temporary structures

Our temporary structures have the credentials to meet all challenges and excel when demand for quality storage on location or at the studio outweighs supply,

Our temporary buildings measure 8 metres to the eave and 12 metres to the apex with clear spans up to 40 metres. This hybrid temporary building design bears all the characteristics of a standard A-Frame structure, but with greatly improved strength and ability to be fully clad in steel roof and wall panelling. This creates a semi-permanent, secure, and fit for purpose facility.

This temporary structure can be installed with a cassette floor or onto a concrete slab if HGV’s will be working within the building. Roller shutter and sliding doors are offered as standard and we take a bespoke approach to the design of the building to ensure your production and storage needs are met.

The roof of our non-insulated temporary buildings can be covered with steel panelling and matching flashings to match the walls or if this is not a requirement a single skin PVC roof can be installed as a more cost-effective solution and colour matched to the walling/existing buildings.

This series of non-insulated temporary buildings can be supplied in large spans, at unlimited lengths and provides valuable temporary storage space incredibly quickly and at a fraction of the cost when compared with a conventional build. Modular in their design, de-mountable and re-locatable these temporary structures will add value to any production site.

Non-insulated temporary structure key Features:

• Cost effective
• Limitless size options
• Robust and secure
• Can be supplied with solar panels for efficient energy

Specifications:

• Rapid construction, lead times starting at 10 weeks from order to occupation, subject to scale of project and required groundworks
• Improved weight load capacity due to heavier duty engineered aluminium and steel frame, with load capacity 2 tonne per arch
• Internal heights achievable of up to 12m floor to apex, up to 8m floor to eave
• Uninterrupted clear span widths from 2m up to 40m
• Constructed in 5m bays with an option for limitless extension & bespoke configuration
• Wind loading of 28m / second
• Roof and wall options:
  • Non insulated single skin steel sheet roof and walling
  • Options for inner liner to catch condensation
  • Single skin PVC
• Improved security
• Snow loading of 25kg/m2
• Can be removed and replaced / upgraded as requirements for the building change
• Options to include mezzanines offering storage combined with under mezzanine sound stages / production offices / warehousing
• Water management with industrial guttering and downpipes
• Suspended reinforced flooring to facilitate plant access or options to build onto new or existing slabs offering advice and guidance for any required groundworks
• Roller shutter doors varying heights and widths subject to your needs
• Pedestrian door units
• Ancillary services to include heating, ventilation and cooling (HVAC), lighting, power, scaffold, access, and egress ramps / steps and egress ramps / steps

Thermally efficient, Insulated, modular temporary structures

When a production, TV or filming location calls for a more bespoke, robust, thermally efficient building our thermally efficient insulated temporary structures are the ideal solution. Taking inspiration from our event structures this hybrid temporary building is engineered to withstand higher loads from both wind and snow combined with enhanced thermal and acoustic properties.

Each of our insulated temporary structures can be designed, manufactured, and customised specific to your intended use and site requirements. This unique approach ensures your production is protected and the building suited to its surroundings and application.

Sharing much of the same DNA as our event structures, with optional level cassette flooring and an A-frame construction, this insulated temporary structure has been through a period of evolution and is now constructed as a semi-permanent, heavy duty building with the option to clad both roof and wall elevations with solid steel sandwich panelling, maximising the thermal and acoustic performance.

Further options for the roof come in the form of inflated twin skin PVC offering a more cost-effective solution but with lower acoustic and thermal credentials.

Our insulated temporary structures hit the mark both in terms of performance and visual appeal and would be a key asset to any film or television production.

Insulated temporary structure key features:

• Heat insulated wall panels and roof
• Option for sound insulation
• Robust and secure
• Can be supplied with solar panels for efficient energy

Specifications:

• Rapid construction, lead times starting at 10 weeks from order to occupation, subject to scale of project and required groundworks
• Improved weight load capacity due to heavier duty engineered aluminium and steel frame, with load capacity 2 tonne per arch
• Internal heights achievable of up to 12m floor to apex, up to 8m floor to eave
• Uninterrupted clear span widths from 2m up to 40m
• Constructed in 5m bays with an option for limitless extension & bespoke configuration
• Wind loading of 28m / second

Roof and wall options:

• PIR sandwich panel roof and walling offering high thermal, sound insulating and fire resistance properties (figures below based on 40mm thick panelling, thicker panels available with higher )
  • 59 W/m2.K thermal performance
  • B-s1,d0 roof and wall panel reaction to fire
  • 26db sound insulation
  • Enhanced snow loading of 34kg / m2
• Air filled ‘Thermo roof & gable’
  • Fire retardant and durable PVC manufactured into double layer roof/gable sections kader fed into structure
  • Internal pump system to circulate air within roof ‘pocket’, heated to ambient temperature ~ 18 degrees
  • Increased thermal insulation
  • Reduction in condensation due to removal of cold bridging
  • Snow loading of 25kg / m2

• Options to include internal mezzanines for storage combined with under mezzanine sound stages / production offices / warehousing
  • Additional sound treatment in the form of TABS to create a designated sound stage within the building, credentials as below:
    • TABS to achieve 50 db/m2
    • Further acoustic enhancing options available to achieve desired sound rating / sound reduction specific to your site location
  • Water management with industrial guttering and downpipes
  • Suspended reinforced flooring to facilitate plant access or options to build onto new or existing slabs offering advice and guidance for any required groundworks
  • Ability to partition studio spaces with inclusion of sound insulated ‘Elephant doors’
  • Subdivision of building to create soundproofed production offices, green rooms, dressing rooms, toilets, and any other required facilities
  • Roller shutter doors varying heights and widths subject to your needs
  • Pedestrian, automated, and glazed door units
  • Airlock entrance chamber for noise barrier control into sound stage
